• CAT IV Clamp Meter can measure the Voltage and Current in both very low and high power circuits.
• Accurate True-RMS reading of AC current or voltage with distorted waveform.• Output terminal for connection to recorders.
| AC A |
400.0/2000A ±1.3%rdg±3dgt (0 - 400.0A, 150 - 1700A) (45 - 66Hz) ±2.0%rdg±5dgt (0 - 400.0A, 150 - 1700A) (20Hz - 1kHz) ±2.3%rdg±3dgt (1701 - 2000A) (45 - 66Hz) |
|---|---|
| DC A | 400.0/2000A±1.3%rdg±2dgt |
| AC V |
40.00/400.0/750V ±1.0%rdg±3dgt (45 - 66Hz) ±1.5%rdg±5dgt (20Hz - 1kHz) |
| DC V | 40.00/400.0/1000V±1.0%rdg±2dgt |
| Ω |
400.0/4000Ω ±1.5%rdg±2dgt (Electronic protection (no fuse) up to 600V) |
| Continuity buzzer | Buzzer sounds below 20Ω |
| Hz |
10.0 - 4000Hz±1.5%rdg±5dgt (Input sensitivityCurrent: more than 40AVoltage: more than 10V) |
| Conductor size | Ø55mm max. |
| Output |
Recorder : DC400mV against AC/DC400.0A DC200mV against AC/DC2000A |
| Applicable standards |
IEC 61010-1 CAT IV 600V, CAT III 1000V Pollution degree 2 IEC 61010-031, IEC 61010-2-032, IEC 61326-1, IEC 61326-2-1 |
| Power source | R6 (1.5V) × 2 |
| Dimensions | 250(L) × 105(W) × 49(D)mm |
| Weight | Approx. 540g (including batteries) |
| Included Accessories |
7107A (Test leads), 9094 (Carrying case) R6 (AA) (1.5V) × 2, Instruction Manual |
| Optional Accessories | 7256 (Output cord) |
