• Designed to meet international safety standard IEC 61010-1 CAT IV 600V.
• CAT IV Clamp Meters can measure the Voltage and Current in both every low and high power circuits.• Very useful for power distribution companies, power utilities and maintenance fields.
Now we have promotion activity as below:
1. Buy any Kingrun tester, will get a KEW2200 clamp meter for Free!!
2. You will get 5% discount by online inquiry(just click the green”INQUIRY”bottom and put into your specific inquiry).
3. 2 Years warranty period. Whole lifetime maintenance.
4. 24h online technical support.
| AC A |
0 - 600.0/1000A
±1.5%rdg±5dgt (50/60Hz)
±3.0%rdg±5dgt (40 - 400Hz)
|
|---|---|
| DC A |
0 - 600.0/1000A
±1.5%rdg±5dgt
|
| AC V |
6/60/600V
Auto Ranging
±1.3%rdg±4dgt (50/60Hz)
±3.0%rdg±5dgt (40 - 400Hz)
|
| DC V |
600m/6/60/600V
Auto Ranging
±1.0%rdg±3dgt
|
| Ω |
600/6k/60k/600k/6M/60MΩ (Auto Ranging)
±1%rdg±5dgt (600 - 6M) / ±5%rdg±8dgt (60M)
|
| Continuity buzzer | Buzzer Sounds at 100Ω |
| Frequency/DUTY | 10/100/1k/10kHz (Auto Ranging) / 0.1 - 99.9% |
| Conductor size | Ø40mm |
| Safety Standard |
IEC 61010-1 CAT IV 600V,
IEC 61010-031,
IEC 61010-2-032,
IEC 61326
|
| Power source | R03 (1.5V) (AAA) × 2 |
| Dimensions | 254(L) × 82(W) × 36(D)mm |
| Weight | 310g |
| Included Accessories |
7066A (Test leads)
9094 (Carrying case)
Instruction Manual
|
