Transformer Performance Tester

  • JYW6100A Transformer no-loads and open circuit tester
  • JYW6100A Transformer no-loads and open circuit tester
JYW6100A Transformer no-loads and open circuit testerJYW6100A Transformer no-loads and open circuit tester

JYW6100A Transformer no-loads and open circuit tester

  • Ensures the measurement accuracy under the low power factor
  • Exclusive automatic data locking technology.
  • Two watt meter and three watt meter measurement methods.
  • 8 inch color touch screen
  • Product description: JYW6100A is suitable for loss tesing of low power factory transformer such as amorphous alloy transformer, with high precision and data locked automaticly.
  • INQUIRY


1. JYW6100A can measure transformer open-circuit loss, open-circuit loss, open-circuit current and open-circuit, impedance voltage, zero sequence impedance, line voltage, phase voltage, voltage effective value and average value, three-phase voltage average value, electric current value, power, power factor, frequency and 50HZ harmonic analysis and so on.

2. Two-phase wattmeter and three wattmeter measuring modes.

3. Can lock the testing result, storing data, printing all measurement synchronously

4. With RS485 communication interface can be on line operated by computer.

5. 8.0 inch color LCD, intelligent touch-screen operation.


High performance of MPU (microprocessor) can provide high precise data and fast calculation:




LCD color touching screen provide clear display for all tested value.


Thermosensitive printer provide fast and clear tested value printing.


JYR series winding resistance tester supply RS485 and USB interface for data transmission.

Testing clips are made from pure copper with punch forming , the surface is nickel plating, the handle is insulating, the testing clip is safe, easy handling and well connection.

We supply a infrared temperature measuring gun with tester for free!

KRI will supply fast delivery work to make sure your can receive tester in time!





TECHNOLOGY SPECIFICATION:

TYPE

JYW6100

JYW6100A

Voltage testing range

AC 10~1000V

Current testing range

AC 0.1~50A

AC 0.1~100A

Accuracy

Voltage: 0.1% ±0.005V(40~70Hz)

0.5% ±0.005V(70~200Hz)

Current: 0.1% ±0.0002A(40~70Hz)

0.5% ±0.0002A(70~200Hz)

Power: P x 0.1% ± (U x I x 0.02%) ±0.05W

Power supply in operation

AC220V±10%, 50Hz

Temperature in operation

-20~40℃

Relative humidity

≤80%RH,  No forming dew

Volume

L420mm x W321mm x H200mm

L380mm x W420mm x H 220mm

Net weight

6.9 kg

12kgs
