What Can Nameplate Information Tell Us About the Performance of a 20 kV Vacuum Circuit Breaker (VCB)?
When selecting or inspecting a 20 kV Vacuum Circuit Breaker (VCB), the nameplate provides essential information about its performance and operating conditions. A typical 1250 A VCB nameplate includes the following parameters:
Rated Voltage: 24 kV
Although the system voltage is 20 kV, the VCB is rated at 24 kV to provide insulation margin and ensure safe operation.
Rated Current: 1250 A
Indicates the breaker can continuously carry 1250 A without overheating.
Rated Frequency: 50 Hz
Suitable for 50 Hz power systems, compliant with medium-voltage distribution standards.
Rated Short-circuit Breaking Current: 25 kA / 3 s
The breaker can withstand a maximum short-circuit current of 25 kA and safely interrupt it within 3 seconds, protecting the electrical system.
Rated Operating Sequence: O-0.3s-CO-3min-CO
Specifies the breaker’s operation cycle: Open – Close (0.3 s) – Open – 3-minute rest – Close again, ensuring fast operation and load adaptability.
Rated Withstand Voltage: 50/125 kV
Includes power-frequency AC withstand voltage 50 kV and lightning impulse withstand voltage 125 kV, verifying insulation strength.
Closing Coil Voltage: AC/DC 100 ~ 125 V
Ensures the closing coil matches the control power for reliable operation.
Opening Coil Voltage: DC 100 ~ 125 V
Ensures the opening coil voltage is compatible with the control source, enabling safe breaker interruption.
Understanding these nameplate parameters helps engineers correctly select, install, and operate a VCB, improving system safety and reliability. The nameplate serves not only as the breaker’s “ID card” but also as a key reference for performance and compatibility.
